PTFE Tube

  • PTFE tube Suppliers
PTFE tube Suppliers

PTFE tube Suppliers

  • ID:
  • Time:2023-01-10
  • Description:PTFE tube SuppliersProduct Size:PTFE/ tube:extrusion methodthickness 0.5-2mm, 7kgs per roll,size such as 4*6mm,6*8mm,8*10mm,10*12mm,12*14mm etc..PTFE/ pipeextrusion methodthickness 2mm to 5mmLength <4.2msize such as 30*22*4200mm etc.PTFE/ bush, hollow, sleevesMold methodthickness 5mm

PTFE tube Suppliers



聚四氟乙烯管


聚四氟乙烯

聚四氟乙烯管

聚四氟乙烯管

聚四氟乙烯管

聚四氟乙烯管


Product Size:


PTFE/ tube:


extrusion method


thickness 0.5-2mm, 7kgs per roll,


size such as 4*6mm,6*8mm,8*10mm,10*12mm,12*14mm etc..





PTFE/ pipe


extrusion method


thickness 2mm to 5mm


Length <4.2m


size such as 30*22*4200mm etc.





PTFE/ bush, hollow, sleeves


Mold method


thickness 5mm to 50mm


length <300mm


size such as 100*63mm*200mm








PTFE SHEET , sheet


PTFE / molded sheet square


3~120 ± 0.30~± 0.50 1000 x 1000


3~70 ± 0.30~± 0.60 1200 x 1200


3~60 ± 0.30~± 0.60 1500 x 1500


3~60 ± 0.50~± 1.00 1000 x 2000


Any other small size or PTFE round sheet we can do as order.





PTFE / Skived Sheet


0.1~12.0 <1200 ≥200m per roll for 1mm thickness


0.5~6.0 <2000


0.5~5.0 <2700


* We can supply such big semi product for 1mm sheet 200m length in roll.





PTFE extruded rod


5mm-150mm1000, 2000 mm length


5mm-200mm 1000mm


PTFE molded rod


180-250 1000mm


280-330 300 mm


400-500 200mm





Chemical Properties:


1 electric insulation material.


2 Excellent electrical properties


3 Good low and high temperature resistance -250-260C


4 heat-conductive,


5 Self lubricate with lowest co-efficient of friction,no oil lubrication


6 acid and alkali resistance, Chemical resistant


7 non-inflammable,anti-aging etc..





PTFE Products:


PTFE ROD/PIPE: molded rod/pipe and extrusion rod/pipe


PTFE SHEET: molded sheet and skived sheet


PTFE FILM: directional, half directional, non-directive film


PTFE TAPE/BALL/GASKET/SEAL/PUMP/PACKING and so on ON SELL





Physical:


Opaque, white, used within -180oC - +260oC for no load;


Essential color, or any other color as your order.


It should be homogeneous, with smooth surface without rift, crack, air bubble, flatted and mechanical scratch, a few exogenous impurities are permitted.





Application:


It is widely used as Sealing, insulate or lubricate parts in oil and chemical industry. Or for Capacitor dielectric, wire isolation, electrical instrument isolation in electric industry.





PTFE filled products:


Glass Fiber:enhance wear resistance and chemical resistance, Increases compressive strength, rigidity. Reduces creep and cold flow.


Graphite:Extremely low coefficient of friction, Fairy good compressive strength, good wear resistance.


Carbon: good thermal and chemical resistance, Resistance to deformation, Increases compressive strength, hardness, wear, and load properties. Various types and amounts of carbon can be added to alter conductivity.


Bronze:Enhanced dimensional stability and compressive strength, Increases hardness and wear resistance, high thermal conductivity. Not suitable for corrosive or electrical applications


Molybdenum Disulfide:Increases hardness, stiffness, and wear.Minimal effect on chemical and electrical properties.
